FLASH VIVO Y15 KITKAT 4.4.2

Vivo Y15 versi kitkat 4.4.2 , klo firmware yang PD1304BW_EX_A_2.5.1-update-full.zip masih JB 4.2.2. Buat flash pasti gagal. Tampilan recovery seperti ini : ALPS.KK1.MP1.V2.46

Download firmwarenya stock rom DOWNLOAD DISINI
Download Flash Toolnya DOWNLOAD DISINI
Driver bila belum punya instal dulu driver mtknya
Untuk tutorial flash via Flash tool bisa dilihat DISINI

GAMBAR STICKER BODY BELAKANG VIVO Y15 KITKAT

FLASH VIVO Y15 KITKAT VIA FLASHTOOL

Start at : [1/26/2016 / 11:43:13 PM]
Operation : Check / Read Info [ v1.40 ]

1. Power Off Phone , Remove battery , Insert back
2. Insert USB cable. In some cases require hold BootKey

Wait for phone...
Phone found! [ 3 ]
Sync...
Inital regs read done
Boot Info :
BB_CPU_ID : 6582
BB_CPU_HW : CA01
BB_CPU_SW : 8A00
BB_CPU_SB : 0001
BB_CPU_NM : [MediaTek] MT6582_S00
Processing BROM stage
SecCfgVal : 0x00000000
BromVersion : 0xFF
BLVersion : 0x01
Preloader Status : Alive
Processing DA stage
DA Select done , sending
DA Ver : MTK_AllInOne_DA_v5.1540.01.01
NAND_ID : 00000000000000000000000000000000
eMMC_ID : 90014A4834473164040505A2DA1442CD
DA Stat : v4.2 on BBID : 0x87
DA Sent. Configure setting now ...
DA started successuflly
eMMC FlashIC initialized
[eMMC] : FLASH_VEN : 0090 , OEM : 014A
[eMMC] : FLASH_INF : [HYNIX] , d1G4
[eMMC] : FLASH_CID : 90014A4834473164040505A2DA1442CD
[eMMC] : FLASH_EXT : 0x00400000 , 0x00400000 , 0x00400000
[eMMC] : FLASH_LEN : 0x00000000E9000000
[eMMC] : FLASH_UCP : 3728 MiB
INT RAM    : 0x00020000
EXT RAM    : 0x20000000
BOOT TYPE : EMMC_FLASH_BOOT
SOC VERIFY : C1
Boot Ok!

[AP] : Initial info read Ok!

Brand     : vivo
ProdName : Y15
ProdModel : vivo Y15
Device    : Y15
AndroidVer: 4.4.2
MTKxCPU   : MT6582
MTKxPRJ   : ALPS.KK1.MP1.V2.46

MODEM :
BaseBand : MT6582_S00_MOLY_WR8_W1315_MD_WG_MP_V62_P8_1_wg_n

EXTRA :
LCD [0] : PD1304CT_TM_NT35510
LCD [1] : PD1304CT_BYD_NT35510
LCD [2] : PD1304CT_default
LCD Res : 854x480
TOUCH [0] : ft5336
CAM [0] : ov5648_mipi_raw
CAM [1] : hi255a_mipi_yuv
MODEM : mt6582_demo_hspa_sky_18_PD1304CW_EX
LOCALE : en_US es_ES zh_CN zh_TW ru_RU pt_BR fr_FR de_DE tr_TR it_IT in_ID ms_MY vi_VN ar_EG th_TH pt_PT   nl_NL el_GR hu_HU tl_PH ro_RO cs_CZ iw_IL my_MM km_KH ko_KR pl_PL es_US bg_BG hr_HR lv_LV lt_LT sk_SK uk_UA de_AT da_DK fi_FI nb_NO sv_SE en_GB

Done!
Elapsed: 00:00:24

Chinese Miracle II [MTK module] v 1.40

Start at : [1/27/2016 / 2:26:32 AM]
Operation : Read Flash [ v1.40 ]

1. Power Off Phone , Remove battery , Insert back
2. Insert USB cable. In some cases require hold BootKey

Wait for phone...
Phone found! [ 3 ]
Sync...
Inital regs read done
Boot Info :
BB_CPU_ID : 6582
BB_CPU_HW : CA01
BB_CPU_SW : 8A00
BB_CPU_SB : 0001
BB_CPU_NM : [MediaTek] MT6582_S00
Processing BROM stage
SecCfgVal : 0x00000000
BromVersion : 0xFF
BLVersion : 0x01
Preloader Status : Alive
Processing DA stage
DA Select done , sending
DA Ver : MTK_AllInOne_DA_v5.1540.01.01
NAND_ID : 00000000000000000000000000000000
eMMC_ID : 90014A4834473164040505A2DA1442CD
DA Stat : v4.2 on BBID : 0x87
DA Sent. Configure setting now ...
DA started successuflly
eMMC FlashIC initialized
[eMMC] : FLASH_VEN : 0090 , OEM : 014A
[eMMC] : FLASH_INF : [HYNIX] , d1G4
[eMMC] : FLASH_CID : 90014A4834473164040505A2DA1442CD
[eMMC] : FLASH_EXT : 0x00400000 , 0x00400000 , 0x00400000
[eMMC] : FLASH_LEN : 0x00000000E9000000
[eMMC] : FLASH_UCP : 3728 MiB
INT RAM    : 0x00020000
EXT RAM    : 0x20000000
BOOT TYPE : EMMC_FLASH_BOOT
SOC VERIFY : C1
Boot Ok!

Reading Flash Conent now ...

Brand     : vivo
ProdName : Y15
ProdModel : vivo Y15
Device    : Y15
AndroidVer: 4.4.2
MTKxCPU   : MT6582
MTKxPRJ   : ALPS.KK1.MP1.V2.46

[Read Ok] : preloader_bbk82_cwet_kk.bin
[Read Ok] : MBR
[Read Ok] : EBR1
[Read Ok] : lk.bin
[Read Ok] : boot.img
[Read Ok] : recovery.img
[Read Ok] : secro.img
[Read Ok] : logo.bin
[Read Ok] : EBR2
[Read Ok] : system.img
[Read Ok] : cache.img
[Read Ok] : userdata.img
[Read Ok] : fat.img

[ScatCFG] : MT6582 / V1.1.1 / bbk82_cwet_kk / EMMC
FW Size : 1377 MiB
Scatter saved to : G:\InfinityBox\CM2MTK\Flash\normal\MT6582__vivo__vivo_Y15__Y15__4.4.2__ALPS.KK1.MP1.V2.46\

All done!

SCATTER VIVO Y15 MT6582_Android_scatter.txt

######################################-=INFINITY-BOX=-######################################################
#
# General Setting
#
####################################-=CHINESE MIRACLE=-#####################################################
- general: MTK_PLATFORM_CFG
info:
    - config_version: V1.1.1
      platform: MT6582
      project: bbk82_cwet_kk
      storage: EMMC
      boot_channel: MSDC_0
      block_size: 0x20000
############################################################################################################
#
# Layout Setting
#
############################################################################################################
- partition_index: SYS0
partition_name: PRELOADER
file_name: preloader_bbk82_cwet_kk.bin
is_download: true
type: SV5_BL_BIN
linear_start_addr: 0x0
physical_start_addr: 0x0
partition_size: 0x1400000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: BOOTLOADERS
reserve: 0x00

- partition_index: SYS1
partition_name: MBR
file_name: MBR
is_download: true
type: NORMAL_ROM
linear_start_addr: 0x1400000
physical_start_addr: 0x1400000
partition_size: 0x80000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS2
partition_name: EBR1
file_name: EBR1
is_download: true
type: NORMAL_ROM
linear_start_addr: 0x1480000
physical_start_addr: 0x1480000
partition_size: 0x80000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS3
partition_name: PRO_INFO
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0x1500000
physical_start_addr: 0x1500000
partition_size: 0x300000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: PROTECTED
reserve: 0x00

- partition_index: SYS4
partition_name: NVRAM
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0x1800000
physical_start_addr: 0x1800000
partition_size: 0x500000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: BINREGION
reserve: 0x00

- partition_index: SYS5
partition_name: BACKUP
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0x1D00000
physical_start_addr: 0x1D00000
partition_size: 0xA00000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: PROTECTED
reserve: 0x00

- partition_index: SYS6
partition_name: PROTECT_F
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0x2700000
physical_start_addr: 0x2700000
partition_size: 0xA00000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: PROTECTED
reserve: 0x00

- partition_index: SYS7
partition_name: PROTECT_S
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0x3100000
physical_start_addr: 0x3100000
partition_size: 0xA00000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: PROTECTED
reserve: 0x00

- partition_index: SYS8
partition_name: SECCFG
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0x3B00000
physical_start_addr: 0x3B00000
partition_size: 0x20000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: INVISIBLE
reserve: 0x00

- partition_index: SYS9
partition_name: UBOOT
file_name: lk.bin
is_download: true
type: NORMAL_ROM
linear_start_addr: 0x3B20000
physical_start_addr: 0x3B20000
partition_size: 0x60000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS10
partition_name: BOOTIMG
file_name: boot.img
is_download: true
type: NORMAL_ROM
linear_start_addr: 0x3B80000
physical_start_addr: 0x3B80000
partition_size: 0x1000000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS11
partition_name: RECOVERY
file_name: recovery.img
is_download: true
type: NORMAL_ROM
linear_start_addr: 0x4B80000
physical_start_addr: 0x4B80000
partition_size: 0x1000000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS12
partition_name: SEC_RO
file_name: secro.img
is_download: true
type: NORMAL_ROM
linear_start_addr: 0x5B80000
physical_start_addr: 0x5B80000
partition_size: 0x600000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS13
partition_name: MISC
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0x6180000
physical_start_addr: 0x6180000
partition_size: 0x80000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: INVISIBLE
reserve: 0x00

- partition_index: SYS14
partition_name: LOGO
file_name: logo.bin
is_download: true
type: NORMAL_ROM
linear_start_addr: 0x6200000
physical_start_addr: 0x6200000
partition_size: 0x300000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS15
partition_name: EBR2
file_name: EBR2
is_download: true
type: NORMAL_ROM
linear_start_addr: 0x6500000
physical_start_addr: 0x6500000
partition_size: 0x80000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS16
partition_name: EXPDB
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0x6580000
physical_start_addr: 0x6580000
partition_size: 0xA00000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: INVISIBLE
reserve: 0x00

- partition_index: SYS17
partition_name: ANDROID
file_name: system.img
is_download: true
type: EXT4_IMG
linear_start_addr: 0x6F80000
physical_start_addr: 0x6F80000
partition_size: 0x53300000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS18
partition_name: CACHE
file_name: cache.img
is_download: true
type: EXT4_IMG
linear_start_addr: 0x5A280000
physical_start_addr: 0x5A280000
partition_size: 0x6400000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS19
partition_name: USRDATA
file_name: userdata.img
is_download: true
type: EXT4_IMG
linear_start_addr: 0x60680000
physical_start_addr: 0x60680000
partition_size: 0x46600000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS20
partition_name: FAT
file_name: fat.img
is_download: true
type: NORMAL_ROM
linear_start_addr: 0xA6C80000
physical_start_addr: 0xA6C80000
partition_size: 0x41A80000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00

- partition_index: SYS21
partition_name: BMTPOOL
file_name: NONE
is_download: false
type: NORMAL_ROM
linear_start_addr: 0xFFFF00A8
physical_start_addr: 0xFFFF00A8
partition_size: 0x1500000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: false
is_reserved: true
operation_type: RESERVED
reserve: 0x00
